Rising Barrier Systems
Powered by advanced technology and local manufacturing expertise, rising barrier systems are increasingly being used across a wide range of applications today. They are designed for all types of high-risk areas or locations that require controlled access. Typical usage areas include military zones, oil fields, security facilities, airports, occupational safety areas, and the controlled entry and exit points of corporate and holding buildings.
Thanks to their high resistance to vehicle impacts, rising barrier systems have also become a preferred solution in occupational safety applications in recent years. These systems operate based on different mechanisms, including hydraulic rising barrier systems, pneumatic rising barrier systems, and electromechanical rising barrier systems.
Custom-manufactured rising barrier systems vary in price depending on the installation area, selected model, and available configuration options.
Height: 500 – 600 - 700 – 800 - 900 - 1000 mm
Width: 2000 - 3000 - 4000 - 5000 - 6000 mm
Wall Thickness: 10 mm
Movable Part Sheet Metal Type: ST 37-3 N / ST 44-3
Protective Sheet Metal: Galvanized
Operation Type: Hydraulic
Power Supply: 3ph AC 380V (±10) 50/60 Hz.
Opening - Closing Time: 4 - 6 / 6 - 8 seconds
Control Panel: Arma Card [EE51KAR]
Security Feature: Loop Detector and Detection Systems
Operating Temperature Range: -25 °C / +60 °C
Manual Lowering: Ball Valve
Warranty Year: 3 years
Warranty Extension: Yes
Protection Against Manufacturing Defects: 10 years
Compatible with all Access Control Systems with Arma Card.
